452 Theories and techniques of oral implantology

Fig. 10-247. The template was then fitted in the mouth. (From Linkow, L. I.: Prefabricated endosseous implant prostheses, Dent. Concepts 10 [3] :2-10, 1967.)

Fig. 10-248. The template was secured to the implants by screwing the small set screws through it.

Fig. 10-249. Posteriorly, pin implants were driven through the predetermined holes in the template to avoid the low floor of the maxillary sinus.

Fig. 10-250. The pins were secured to each other with acrylic cores that were prepared for full crown coverage.

Fig. 10-251. A full arch acrylic-over-gold fixed denture was then cemented over the template with a temporary form of cement. Arrows mark the palatal border of the template.

vertical extensions of the template so that they were flush with it (Fig. 10-246). The template was tried in the patient's mouth (Fig. 10-247), and the small set screws were inserted through the template and into the internal threads of the implants (Fig. 10-248).

The triplant pins were then drilled posteriorly through predetermined holes in the template and the excess length cut away (Fig. 10-249). The terminal ends of the pins were joined with quick cure acrylic, and the hardened acrylic cores were then prepared for full crown preparations (Fig. 10-250).

An elastic impression of the maxilla and a wax interocclusal record of centric relation were taken. The full arch acrylic-over-gold splint was processed and cemented into position with a hard cement (Fig. 10-251). A Panorex reveals the entire case (Fig. 10-252).
